Features

• Pump volute casing constructed from Cast Iron FG260 (as per IS 210/ISO 186), with a vertical discharge port, suitable for liquids up to 50u00b0C.
• Semi-open impeller made from Cast Iron FG260 (as per IS 210/ISO 186).
• Pump shaft crafted from stainless steel (ASTM A582, AISI 410 grade).
• Fitted with a mechanical shaft seal made from Carbon/Ceramic/NBR/AISI 304.
• Close-coupled to a dry submersible motor, class F insulation, IP68 protection, 2900 rpm, rubber-sealed cable entry.
• Suitable for S1 duty when fully submerged, S3 duty when partially submerged, available in 1-phase (240V) and 3-phase (415V) versions.
• All cast iron parts are CED-coated for corrosion resistance, with a uniform coating thickness of 20-30 microns.

Variety & Range

Flow range- up to 11 mu00b3/h

Head range- up to 10.8 metres

Rating u2013 0.18kW & 0.37 kW

Rated Speed u2013 2850 rpm
