Features

• Designed for mounting on coolant lubricant tanks, with the pump end immersed in the coolant.
• Hydraulic components made from stainless steel AISI 304.
• Equipped with TEFC induction motors built to IEC standards, rated for IE2 efficiency.
• Cast iron parts feature CED (Cathode Electrode Deposition) coating for corrosion resistance, ensuring uniform coating thickness of 20-30 microns.

Variety & Range

Flow range- up to 8.5 mu00b3/h

Head range- up to 212 meters

Rating u2013 0.37-5.5 kW

Rated Speed u2013 2900 RPM
